The Navy Series delivers powerful, efficient, and reliable electric propulsion with outputs from 3 to 6 kW (equivalent to 6–9.9 HP). Its direct-drive system ensures quiet operation and minimal maintenance, while integrated hydrogeneration technology allows the battery to recharge under sail. Combining performance with sustainability, the Navy Series is the ideal choice for boaters who demand both power and eco-friendly innovation.
Interested in learning more about EPROPULSION engines?
Contact us to schedule an appointment at our showroom, where we will be happy to answer all your questions and help you choose a boat that will meet all your needs and desires.
| TRANSOM HEIGHT | SHAFT LENGTH |
|---|---|
| 40-50 cm / 15.7-19.7 inches | Short |
| Higher than 50 cm / 19.7 inches | Long |
| NAVY 3.0 EVO | NAVY 6.0 EVO | |
|---|---|---|
| Power | 3 kW (6HP equivalent**) | 6 kW (9.9HP equivalent**) |
| Input voltage | 39V – 60V | 39V – 60V |
| Recommended Battery | ePropulsion E-Series Battery | ePropulsion E-Series Battery |
| Motor Weight | Short: 24.3 kg / 53.6 lbs Long: 27.5 kg / 60.63 lbs | Short: 28.5 kg / 62.8 lbs Long: 29.5 kg / 65 lbs |
| Propeller | 10.2" × 6.7" 2-blade composite propeller | 12.6" × 10.8" 3-blade composite propeller 13.4" × 8.5" 3-blade composite propeller 12.6" × 8.7" 3-blade aluminum propeller (optional) |
| Trim / Tilt Angle | 0°, 5°, 10°, 15°, 20°, 35°, 50°, 65 and 80° | 0°, 5°, 10°, 15°, 20°, 35°, 50°, 65 and 80° |
| Shaft Length | Short, Long | Short, Long |
| Control | Evo Tiller Evo Top Mount Control Evo Side Mount Control Evo Dual Remote Control | Evo Tiller Evo Top Mount Control Evo Side Mount Control Evo Dual Remote Control |
| Hydrogeneration | Yes | Yes |
| Motor | Brushless DC motor | Brushless DC motor |
| Direct Drive | Yes | Yes |
Tailored Control and Display Solutions to Suit Every Boater
1. Digital Display
Provides real-time monitoring of key information including power output, remaining runtime, battery level, voltage, and more.
2. Electric Start
Start instantly at the push of a button, eliminating the effort of pull starts.
3. Magnetic Kill Switch
Enhances safety by instantly shutting down the motor in case of emergency.
4. Smooth Throttle Changing
Delivers precise throttle response with a clear, comfortable feel in both forward and reverse.
5. Adjustable Max Power Output
Allows you to set a maximum throttle limit, making the motor suitable for children or rental applications.
6. Ambidextrous Operation
Throttle can be operated comfortably from either the left or right hand for flexible control.
| NAVY 3.0 EVO | |||
|---|---|---|---|
| POWER (WATTS) | SPEED (MPH/KPH) | RUNTIME (HH:MM) | RANGE (MILE/KM) |
| 300 | 3.7 / 6 | 13:20 | 49.3 / 79.3 |
| 550 | 4.7 / 7.5 | 7:25 | 35 / 56.3 |
| 1000 | 5.3 / 8.6 | 4:00 | 21.2 / 34.1 |
| 1500 | 6 / 9.7 | 2:40 | 16 / 25.7 |
| 2000 | 6.3 / 10.2 | 2:00 | 12.6 / 20.4 |
| 2500 | 8 / 12.8 | 1:35 | 12.7 / 20.5 |
| 3000 | 10.2 / 16.4 | 1:20 | 13.6 / 21.9 |
| NAVY 6.0 EVO | |||
|---|---|---|---|
| POWER (WATTS) | SPEED (MPH/KPH) | RUNTIME (HH:MM) | RANGE (MILE/KM) |
| 500 | 4 / 6.5 | 18:00 | 72 / 116 |
| 1000 | 5 / 8 | 9:00 | 45 / 72 |
| 2000 | 6.7 / 10.8 | 4:30 | 30.2 / 48.6 |
| 3000 | 8 / 13 | 3:00 | 24 / 39 |
| 4000 | 11.5 / 18.5 | 2:15 | 25.9 / 41.7 |
| 5000 | 13.5 / 21.8 | 1:50 | 24.7 / 39.8 |
| 6000 | 15 / 24.3 | 1:30 | 22.5 / 36.5 |
