The H-Series is our 60–250 kW inboard range, purpose-built for large sailing yachts and motor vessels from 60 to 100 feet (18–30 metres) with full displacements of up to 200 tons. Delivering powerful performance with minimal noise, reduced vibration, and zero exhaust emissions, the H-Series sets a new standard for clean, efficient propulsion in larger craft.
Interested in learning more about EPROPULSION engines?
Contact us to schedule an appointment at our showroom, where we will be happy to answer all your questions and help you choose a boat that will meet all your needs and desires.
| H-100 | |
|---|---|
| Rated Voltage | 540 VDC |
| Rated Power | 100 kW |
| Rated Torque | 797 Nm |
| Rated Speed | 1150 rpm |
| Rated Efficiency | 96% |
| IP Rating | IP67 |
| Insulation Level | H |
| Cooling Methods | Water Cooling |
| Operating Temperature | -25℃ ~ +55℃ |
| Dimensions | 443 x 315 mm (17.4 x 12.4 in) |
MODULAR DESIGN
The H-Series motors are built on a modular architecture, giving manufacturers the flexibility to extend both power and range by adding motors, controllers, and batteries. This adaptability allows tailored power configurations to meet specific vessel requirements, making the system highly scalable and future-ready.
BOATING IoT SYSTEM: SMART AND CUSTOMISABLE
The ePropulsion Boating IoT platform delivers smart, customisable solutions for remote monitoring and integrated management. Key metrics such as speed, power, mileage, tracking, and safety alerts can be configured to suit different operational needs. Through the web portal, boat owners gain real-time insights and full oversight of their vessels for improved safety and efficiency.
OPTIMUM PERFORMANCE THROUGH PIONEERING TECHNOLOGY
Equipped with advanced permanent magnet motor technology, the H-100 redefines performance, surpassing diesel equivalents. Delivering a maximum torque of 2,000 Nm and an exceptional 96% efficiency, it outperforms traditional 100 kW AC asynchronous motors, setting a new benchmark in marine propulsion.
SAFETY AND RELIABILITY
-IP67 Waterproofing
-Anti-Corrosion Measures
-High-Accuracy Position Feedback
-High Torque Density
-Closed-Loop Cooling System
